pin layout NI 9214

[Steffen01]

Hello,

does anyone have the pinout for a NI 9214 module? It has a connector that looks like a 3 pin IDE socket. I am thinking about some cable tail like this

https://www.harwin.com/products/M83-LFD1F2N54-0000-000/

and then make up some PCB board with 16 sockets, so I can plug sensors into that. Would make things easier, because we will not have sensors connected all the time. So its not much point to hard wire them in. Or should I buy that NI connector, its some 300+ dollars.

[Steffen01]

something on the lines of a DIN41612 connector to be more precise

[MChanchu]

According to the NI 9214 Wiring section of the Getting Started Guide, the TB-9214 should be used with the module. Because of this, NI does not provide the pinout for the NI 9214 module.

[Steffen01]

its a lazy AUD 550 for that one, so I thought its cheaper to build one. On the picture, apart from Made in Hungary (they make AUD 5 on this), there are 2 diodes or so, so maybe there is something special about it. Not just some wiring.
