When analyzing execution performance it would really help if we had a simple yet comprehensive way to check a VI and all it's dependencies for "things" that would create a UI thread swap / access.
... View more
According to some engineers that I have spoken to in the prototyping industry, Windows 10 IoT is gaining some traction as a preferred embedded OS for developing ideas. Windows 10 IoT, as I understand it, is delivered in 3 different versions: Core, Enterprise, and Enterprise Mobile. Now where Core is built as a .NET application and lacks some of the system capabilities of Windows 10, the Enterprise version is built as a Win32 OS and is closest to Windows 10 as it is now.
If resources allow, it might be beneficial to see some future support for at least this version of Windows 10 IoT to meet the demands of a growing body of engineers who will want to integrate LabVIEW executables with their Windows 10 IoT powered devices.
... View more
I´d appreciate an event that is called whenever there is a change of Top cell (row). Several times I needed to "align" visible content of two objects (listboxes, trees, etc.). Value change or mouse scroll event can be used but still I´ve found no way how to catch when the user uses scrollbar arrows or draging scrollbar position indicator. The only solution I found is to keep it aligned by periodically reading out Top row visible property of one object and set it for another one. That requires code in Timeout event that is called very often (otherwise it is noticeable for user) causing performance drop.
... View more
The goal of this idea is to make it easy for the LabVIEW ecosystem to create reusable libraries for LabVIEW that would be type independent. Let's think for a second dictionaries, also called as key-value stores. Dictionaries are data structures that allow storing and retrieving values with a specific key. To create a generic reusable strongly typed dictionary is currently impossible with the LabVIEW type system. One can create a dictionary that is type specific but then it's not reusable. Or one can create a reusable dictionary but then it's not strongly typed. Type Parameters and Parametrized Generic Types as explained in this idea would allow creating strongly typed dictionaries that are widely reusable across applications. Specifically type parameters and parametrized generic types would allow LabVIEW ecosystem to develop highly reusable strongly typed components to solve various common programming problems. This would allow National Instruments to put more focus on the core of the language as the LabVIEW ecosystem could solve much wider range of problems that preivously have required National Instruments to contribute.
Add a new control type Type Parameter to LabVIEW that augments the current Control , Type Def and Strict Type Def control types. The Type Parameter type would act like a regular Type Def control with one special and important distinction. You could wire anything to an input terminal expecting a specific Type Parameter type and the downstream type would adapt at compile time to the type wired to the type parameter input.
In a single VI type parameter could be used in multiple places but all instances of the type parameter would adapt to the same type.
When a VI that uses Type Parameters in the front panel is used on a block diagram, the template VI is replaced by the compiler by a type specific instance that has adapted the type parameters to the type wired to the Type Parameter input. Notice below how in our VI the control and the indicator were of type Type Parameter with a default type of DBL and the instance got adapted to type U32 that was wired to the input.
The same type parameter could be used on multiple inputs of a VI.
And all of the type parameters would adapt to the same type when the VI is being used.
Note that in the above example we chose the element of the array to be a specific type specified by a type parameter. However the arrays themselves could as well have been specified by a type parameter.
So far we have focused on VI boundary where type parameters adapt the whole VI to specific type or types if multiple different type parameters are being used in the connector pane of the VI. Type parameters can also be used in composite types (e.g. arrays, clusters, classes) and the downstream composite types would adapt to what is wired to the type parameter input.
Note that x and y as instances of the same type parameter have to be of the same or compatible type.
Type parameters can also be used in class private data to create parameterized custom types. This is where type parameters become extremely powerful. Let's assume that we have a class 3D Vector.lvclass that has three instances of a "Data Element.ctl" Type Parameters. The default type of the Data Element is set to be DBL. The cluster private data has three instances of the Data Element, one for each of X, Y and Z.
Now we could create a Create 3D Vector method VI for this class that allows us to construct type parametrized instance of the class type.
Now calling this Create 3D Vector.vi with string as the inputs for type parametrized inputs X, Y and Z will create an instance of class 3D Vector with compile time type 3D Vector[String].
And this is where we now start seeing the superpowers of type parameters and parametrized types as well as generic type parameterized VIs that go along with them. Now we have a capability of creating custom VIs and custom types that both can adapt to different parameter types at usage time.
Let's get back to the question of dictionaries. We could easily construct a dictionary that allows the key type to be parametrized with one parameter and the value type to be parametrized with another parameter. For example we could use the dictionary with I32s as keys and Strings as values. Or we could use it with Strings as keys and File Paths as values. Constructor for such custom type would be trivial to create.
Once we have constructed the dictionary we would naturally like to use it. We could now use method VIs of the Dictionary class to add and fetch elements from the dictionary. As an example Get Element By Key would look something like this in it's simplest form.
Note that Dictionary In is type parametrized with two different type parameters Key Type and Value Type. In the class library there is a Type Parameter control Key Type.ctl and Value Type.ctl. Now type parameter Key Type.ctl is used both inside the private data of the class and on the fron panel as the Key input, the type of these two must be the same. The same is true for the Value Type element of private data and the Value indicator that both derive from Value Type.ctl type parameter. The has function is any function that can convert any LabVIEW types to some strings that we can use as keys for the variant attribute node. We are using variant attributes as the store implementation is this basic example.
Calling the Dictionary with integer as the type parameter and string as the value would look something like this.
As you can see the 0 and empty string will define propagate as type parameter types for Key Type and Value Type in the dictionary wire. Now Add Element.vi would have to adapt to these elections for Key Type and Value Type the moment the Dictionary wire is connected. The Key input immediately change to type INT32 and the Value input to type String. Similar would be true if the wires would be connected in reverse order. Connecting University of Texas string to the Value input of Add Element and connecting number 1 of type INT32 to the Key input of the Add Element would immediately adapt the Dictionary in and Dictionary out inputs to be of type Dictionary[Key Type = INT32, Value Type = String]. A type error would occur if Dictionary in would be of different type.
Type Parametrized Generic Types are an extremely powerful concept to incldue in a language and this idea describes a feasible way to implement them in a visual dataflow model of LabVIEW. This is and has been for maybe ten years my absolute #1 feature I have wanted to see in LabVIEW. I think the time is right for me to officially make this request. Ideally Type Parameters can be bounded but that's a topic for a whole other idea post.
... View more
Languages like 'R', 'Python', and MatLab (yes I use the old name) have these. They are useful.
One of the key ideas in LabVIEW is that the user needs minimal interventions to code a useful result. As more information is encoded in a data type there is more opportunity to make "hands free" code that "just works". I think these two data types can do that.
Primary data type in R
It is Array-like, but NOT an array
each column contains one measurement (row) on one variable
It acts like a list of vectors, but the vectors have the same number of rows, and indexing allows a return of all or subset from all columns
column types are heterogenous - they can be different
column types can be set. A column of 0 vs. 1 can be set as factors/binomial values or as continuous.
There are functions that data analysis folks do every day that are informed by variable type, so the function operating on the inputs doesn't need type specified because it is interior to the table. This means you can say "plot(mydata)" and if your data is set up well, the graph parameters are already specified and useful.
This is from Hadley Wickham, a very famous person in 'R'. He does great work, and his name has high brand value in data-analysis.
Uses the "data.table" package
is able to be screaming-fast (think roller-coaster) especially when used with the "split-apply-combine" approach to data analysis, and SQL-like operations.
is built for handling huge data (100GB tables) quickly and efficiently.
In many applications the same operation is not possible due to memory constraint or viable due to processor overhead can execute adequately (aka wonderfully) by using this data type on the same hardware.
... View more
The recently introduced Raspberry Pi is a 32 bit ARM based microcontroller board that is very popular. It would be great if we could programme it in LabVIEW. This product could leverage off the already available LabVIEW Embedded for ARM and the LabVIEW Microcontroller SDK (or other methods of getting LabVIEW to run on it).
The Raspberry Pi is a $35 (with Ethernet) credit card sized computer that is open hardware. The ARM chip is an Atmel ARM11 running at 700 MHz resulting in 875 MIPS of performance. By way of comparison, the current LabVIEW Embedded for ARM Tier 1 (out-of-the-box experience) boards have only 60 MIPS of processing power. So, about 15 times the processing power!
Wouldn’t it be great to programme the Raspberry Pi in LabVIEW?
... View more
I have a project which compiles to 2 different executable for different hardware targets. I have created 2 Build Specifications which specify different locations for the build output. However, between compiling each one, I must go to the target options, and change a Conditional Disable Symbol definition so that the other .exe is generated. If the Build Specifications definition had a tab to specify the value of Conditional Disable Symbols, and which would take precedence over definitions in the project or the target options, then I could build my 2 executables without changing the target properties.
... View more
(This is different and less controversional than this related old idea)
Arrays of timestamps only contain legal values and can even be sorted. We can use "search 1D array" to find a matching timestamp just fine.
As with DBLs, there might be a very close array value that is a few LSBs off, but well within the error of the experiment so it is sufficient to find the closest value. We can always test later if that value is close enough for what we need or if "not found" would be a better result.
If we have a sorted input array, the easiest solution is "threshold 1D array" giving us a fractional index of a linearly interpolated value. For some unknown reason, timestamps are not allowed for the inputs, limiting the usefulness of the tool. One possible workaround is to convert to DBLs, with the disadvantage that quite a few bits are dropped (timestamp: 128 bits, DBL: 64bits).
Similarly, "Interpolate 1D array" also does not allow timestamp inputs. In both cases, there is an obvious and unique result that is IMHO in no way confusing or controversial.
IDEA Summary: "Threshold 1D Array" and "Interpolate 1D Array" should work with timestamps.
... View more
I have code I want to run in parallel, I've confirmed that if I write the code 3 times to execute in parallel there is no problem doing it. Yet when I try to put the code once in a for loop with iteration parallelism on, set to 3 parallel instances, it will only run 2 at a time because my target cRIO only has two processors. I suppose this is a requirement if we want the code to be truly parallel. But in my case, I'm satisfied with them running pseudo-parallel using whatever behavior happens when I write the code 3 times in parallel and they appear to execute in parallel. So like a timed loop, I'd like an option to set iteration parallelism to be either a) targeted to available processors OR b) just let them be launched in parallel asynchronously regardless of number of processors, and perhaps not truly parallel (with appropriate warnings). See attached image
Note - Specific to Softmotion: I realize there are theoretically other ways to do this asynchronously built into Softmotion, but they did not execute as expected. Yet this is just about the loop iteration parallelism.
... View more
Consider expanding programmatic modification of the Build Process. There is already an Idea here to allow the Pre-Build Action to set the Version Specification before the Build Process (it happens during the Build process, after the before-the-change Version Specification has been cached and used in the Build). However, other Specifications in the Build Spec would be very useful to be able to specify in a (true) Pre-Build Action.
Target Filename (low priority)
Destination Directory (I like to put Builds in Public Documents, but the Public Document folder can "move", though LabVIEW's Get System Directory can find it, so I could "pre-build" a path specific to the given PC)
Build Specification Description (allows the user to include version-specific or Build-Time text)
Version Information (in addition to Version Number, before being used, the other Fields might be useful).
I've noticed references on the Web to automated Builds, and know there are Build VIs that will do a Build. I also know there are a set of "barely-documented" APIs that some have used for this purpose, but I don't know (other than the Set Version Specification, which doesn't work as I expected in a Pre-Build Action) of others. I don't especially want to poke around inside the Project's XML file -- can we consider adding some other "Pre-Build" Set functions? Could (for example) some of these "Build Properties" be set with a Property Node? Maybe this functionality is already there and I've not found it ...
... View more
As shown in below image we can see that, if I index numeric array and wire it with any of the node from numeric function it gives un-aligned wire whereas as same process if I use Boolean function at output of index it gives well aligned wire.
So due to this numeric function node wire to index out terminal makes our code with full of wire bends which is not as per NI LabVIEW coding standards also.
So here, I want to draw attention for NI, to do some correction to specific numeric function nodes so we can make neat and clean code in LabVIEW.
... View more
Currently when I build a dll in Labview, the parameter list defaults to generating len, len2, len3 for the length of each string or array output I have in my function. Not only this but these array length are all dumped at the end of the parameter list and it is difficult to see which parameter matches which length. Please can developers consider having each length parameter after the array that they represent the length off, and name them with the name of the array parameter with Len at the end?
e.g. Currently default behavious produces:
functionName(double temperatureArray, double voltageArray, char errorString, int len, int len2,int len3);
Can this be changed to:
functionName(double temperatureArray, int temperatureArrayLen, double voltageArray, int voltageArrayLen, char errorString, errorStringLen);
... View more
Typical question in development process: "How quickly does my code execute? What runs faster... Code A or Code B?" So, if you're like me, you throw in a quick sequence that looks like this: AHHH! What a mess! It's so hard to fit it in, with FP real estate so packed these days! We need this: Just like my other idea, and for simplicity's sake NI, I would be PERFECTLY happy even if you had to set up the probes during edit mode, and were not able to "probe" while running. As a bonus, this idea may be extrapolated into n timing probes, where you can find delta t between any two of the probes.
... View more
There are times when I leave a VI with modal properties open and then I run the main application that also calls this VI if opened in the development environment. This locks all running windows due to the modal VI. I propose a button in the taskbar that aborts all running VIs OR perhaps a list is opened on right-click of all running VIs :)
... View more
As soon as we have more complicated data structures (e.g. clusters of arrays), a large portion of the FP real estate is wasted taken up by borders, frames and trims, etc. We need a palette full of "Amish" ;) controls, indicators, and containers that eliminate all that extra baggage. We have a few controls already in the classic palette, but this needs to be expanded to include all types of controls, including graphs, containers, etc. A flat control consists of a plain square and some text (numerical value, string, ring, boolean text, etc). A flat container is a simple borderless container. A flat graph is a simple line drawing that would look great on a b&w printer. A flat picture ring looks like the image alone. They have a single area color and a single pixel outline, if both have the same color, the outline does not show. They can also be made transparent, of course. If we look at them in the control editor, there are only very few parts. Now, why would that be useful? Let's have a look a the data structure in the image. There is way too much fluff, distracting from the actual data. If we had flat objects, the same could look as the "table" below. Note that this is now the actual array of clusters, no formatting involved! It is fully operational, e.g. I can pick another enum value, uncheck the boolean, or enter data as in the cluster above. Many years ago in LabVIEW 4, I actually made a borderless cluster container in the control editor and it looked fine, but it was difficult to use because it was nearly impossible the grab the right thing with the mouse at edit time. The main problem of cours is that the object edges completely overlap, making targeted seletion with the mouse impossible. (For example the upper right corner pixel is the corner of an array, a cluster, another array, and an element at the same time.) So what we need is a layer selection tool that allows us to pick what we want (similar to tools in graphics editing software). It could look similar to the context help shown in the picture with selection boxes for each line. Picking an object would show the relevant handles so we can intereact with the desired object. Another possibility would be to hover over the corner and hit a certain key to rotate trough all near elements until the right element is selected, showing it's resize handles. I am sure there are other solutions. As a welcome side effect, redrawing such a FP is relatively cheap. Message Edited by altenbach on 06-03-2009 09:20 AM Message Edited by altenbach on 06-03-2009 09:20 AM
... View more
Classes? OOP? ... Huh?
Even if you don't (yet) work with LV classes, you may have noticed that they are starting to become increasingly widespread in the LV world. In fact, the excellent new Actor Framework that ships with LV2012 relies heavily on classes. LV classes are great but they can impact on your performance as a developer as your application becomes larger. I'd encourage everyone to click the magic KUDOS button for this idea, since classes will likely affect us all sooner or later!
Most class-based architectures contain some degree of linking. One form of linking is inheritance where parent-child relationships are implicitly defined, and another form of linking arises from nesting libraries where classes (e.g.) are placed inside other libraries.
Unfortunately as the linking increases in a project, the IDE starts to become very sluggish! Those who have worked on mid-sized class-based applications know the symptoms:
Opening the "class properties" window takes 10 seconds or more
Renaming a class brings the editor to a standstill
For many projects these symptoms are a minor annoyance, but as your project grows they can become a serious impediment to productivity. Why should it take over 30 seconds to modify a class's inheritance?!
Obviously careful design can reduce linking to some extent, but that just postpones the pain. The reality is that all class-based projects start to suffer from these symptoms once they reach a "resonable" size .
Improve the responsiveness of the LV editor when working with classes.
Highly repetitive tasks such as editing a class library's icon deserve a snappy response from the IDE, regardless of how many classes I have loaded!
Modifying inheritance is a fundamental operation. It should be quick and easy! (See this related idea)
Placing classes in libraries promotes good project organisation. It should *not* bring the editor to a grinding halt!
Others have written about this topic well before me. Here are a few relevant discussions:
Feel free to link more! :smileyhappy:
... View more
As LabVIEW evolves more and more, the compiler takes over an awful lot of code optimisation for us. This leads us to situations where relatively large and important pieces of code can be evaluated at compile time and constant folded which can greatly aid execution speed. This is good. Constant folding can be a great aid when programming but at the moment, it's usage is a bit "hit and miss" due to the opaqueness of the process. We already have constant folding highlighting, which really helps things (even if the feedback is sometimes very hard to understand). But this doesn't always give us enough feedback. What I would like is the option to declare a portion of code as "Requires constant folding" (like a "Precompile" structure). In this way, I can, as a programmer, designate some code which is meant to be evaluated at compile time. If the compiler is unable to constant fold this code, then the VI should be broken. My motivations are three-fold. Sometimes we want to specifically make use of the constant folding capabilities of the compiler, but a small change can result in the code no longer being constant folded. I would like explicit feedback when code I want constant folded is not constant foldable. I have no idea whether code complexity has an effect on the ability to constant fold. Other compiler optimisations (Like unbundle-unbundle inplaceness) are dependent on code complexity. Explicit declaration is not code complexity dependent. When looking at FPGA designs, the ability to perform constant folding of data otherwise requiring resources or affecting performance is very powerful. In such a "Constant folding" code, we could also allow mathematical functions to be used which are otherwise not supported on the target (max/min of an array in a timed loop for example), or creating default data for an array (to be used as Block RAM) based on an existing equation where constants are defined as DBL. One example of FPGA code is automatic latency balancing of several parameter pathways into a process where the code accepts abstract parameter objects whose latency is queried via a dynamic dispatch VI which simply returns a constant. I use dependency injection to tell the sub-VIs which communication pathways they are being given and they can then query the latency and do some static timing calculations for the delays required on different pathways. Tests have shown that this is constant folded and that it is thus possible to write very robust FPGA code which auto-adjusts request indices for parameters in multiplexed code. At the moment, things seem to work but the ability to specifically designate such code as being constant folded would be welcome to make sure I don't accidentally produce a version which doesn't actually return a constant (and my compiles fail, I get timing errors, or just over-use resources).... In the code below, all of the code circled in blue is constant-folded when compiling the FPGA code. In the sub-VIs I have to do some awkward calculations because certain functioanlity is not available on FPGA. By defining this code as requiring explicit constant folding, I could theoretically utilise the full palette of LV functions and also be guaranteed a compile error (LabVIEW error, not Xilinx) if the code thus designated can not be constant folded. So in a way, it's similar to the In place element structure which, when all goes well, should not be needed but there are cases (I've run into some myself) where either small changes in code can make the desired operation impossible or where the code complexity can cause the optimisation to not be performed. As such, it is still required at times to explicitly designate some code paths as being In-Place. I would like to have the same functionality for "Constant folding".
... View more
NI updater kindly informed me that LabVIEW 2014 SP1 was released (even though I uninstalled it shortly after I tried it last year) and out of curiosity, I took a look at the known issues list.
I learned a few interesting things I did not know about, and also that some problems had been reported as long ago as version 7.1.1. This type of stuff looks like bugs that won't be fixed, ever.
For instance, CAR #48016 states that there is a type casting bug in the Formula Node. It was reported in version 8 and the suggested workaround it to use a MathScript Node instead of a Formula Node (where is the "Replace Formula Node by a MathScript Node" contextual menu item?).
Problem: the MathScript RT Module is required. Even in my Professional Development System, this is not included by default. Does this really count as a workaround?
I read: we don't have the resources to fix that bug, or we don't want to break code that expected that bug.
In any case, this bug with most likely never be fixed.
The bottom line is, we can waste a lot of time as users, rediscovering bugs that have been known for a while and will probably never be fixed. As a user, I would really appreciate a courteous warning from NI that there are known traps and have a complete description handily available with the help file related to the affected function.
My suggestion: add a list of known issues (with link to their description) for all objects, properties, functions. VIs, etc, in the corresponding entry in the Help File.
